Four-side Moulder
This machine combines advanced engineering with precision manufacturing for effortless four-side processing of all wood types.
The machine adopts advanced design and manufacturing technology, featuring rational structure, easy operation and excellent performance. It is suitable for four-sided machining of various wood products.
-
worktable
The worktable is specially treated with hard chrome plating, wear-resistant and long service life.
-
Upper horizontal cutterfront & rear pressure plates
The upper horizontal cutter uses springs to control the front and rear pressure plates for
clamping.
-
Lifting and in/out
adjustment of spindleThe upper spindle lifting and left spindle in/out movement are mechanically adjusted with digital display.
-
feed steel roller
The feed steel rollers feature a new tooth profile design and special treatment, ensuring
high feeding efficiency and long service life. Cylinder pressure can be as low as 0.2 MPa.
-
side pressing mechanism
The side pressing mechanism in front ofthe left spindle can be adjusted manually to ensure workpiece stability duringprocessing
-
control panel
Intuitive push-button controlpanel for faster and easier operation.。
-
|
Name |
Unit |
MB626CW |
MB726CW |
|
Max.working width（tool diameter φ140） |
mm |
260 |
260 |
|
Min.working width（tool diameter φ140） |
mm |
20 |
20 |
|
Max.working thickness（tool diameter φ140） |
mm |
160 |
160 |
|
Min.working thickness（tool diameter φ140） |
mm |
10 |
10 |
|
Max.lifting stroke of movable worktable |
mm |
8 |
8 |
|
Max. travel of movable guide plate |
mm |
8 |
8 |
|
Number of spindle |
根 |
6 |
7 |
|
Spindle diameter |
mm |
Φ40 |
Φ40 |
|
Spindle speed |
r/min |
6000 |
6000 |
|
Feeding speed |
m/min |
6-36 |
6-36 |
|
First lower spindle(Straight cutter: φ140 mm, edge trimming cutter: φ165 mm) |
mm |
Φ125-Φ160 |
Φ125-Φ160 |
|
Other spindle |
mm |
Φ112-Φ200 |
Φ112-Φ200 |
|
Chip exhaust pipe diameter |
mm |
6-Φ150mm |
6-Φ150mm |
|
Pressure roller diameter |
mm |
Φ140×Φ35×50 |
Φ140×Φ35×50 |
|
Vertical spindle axial travel |
mm |
40 |
40 |
|
Horizontal spindle axial travel |
mm |
20 |
20 |
|
Overall（L×W×H） |
cm |
4900×2150×1830 |
5400×2150×1830 |
|
Weight |
Kg |
5300 |
5700 |
